SK 9000 B1-B4
货号 504732
Features04
- 灵活应用满足于多种多样的音源
- 支持领夹式传声器、吉他和乐器所使用的3针脚雷莫(Lemo)接头
- 具有坚固性和重量轻的特点——对广播专业应用来说,易于隐蔽在装束之下而不会引起注意
- 镁合金外壳
主要参数
- 重量 (g)approx. 147 g (with rechargeable battery pack BA 61 and belt clip)
- 音频输入端3-pin socket
- 功耗 (Amp)Max. 960 mW
技术参数
Product
- 增益line : -6 dB
Frequency Specifications
- 频率特性Mic: 60-20000 Hz (3 dB)
- 音频频率特性Mic: 60-20000 Hz (3 dB)
Inputs/Outputs
- 音频输入端3-pin socket
Battery & Power
- 功耗 (Amp)Max. 960 mW
- 电池工作时间6.5 h with rechargeable battery pack BA 61
Electrical Properties
- 输入阻抗line : 1 MΩ
Dimensions
- 尺寸76 x 62 x 20 mm L x W x D (with rechargeable battery pack BA 61)
- 高度 (mm)163
- 长度 (mm)199
- 重量 (g)approx. 147 g (with rechargeable battery pack BA 61 and belt clip)
- 宽度 (mm)52.5
- Product height163
- Product weight (g)approx. 147 g (with rechargeable battery pack BA 61 and belt clip)
- Product width52.5
下载24
- Specifications, manufacturer declarations and regulatory information - Digital 9000 series.PDF·1.21 MB下载
- Sennheiser Transmitter Manager - Version 4.1 - Windows.EXE·3.8 MB
下载
- Digital 9000 Firmware Package (SENNPKG) - Version 4.0.1.ZIP·30.54 MB
下载
装箱内容03
- 1 SK 9000
- 1 份补充文件“框架要求和频率使用限制”
- 1 份使用说明书
