MKH 416-P48U3

Article No. 001511

Short shotgun interference tube mic for film, radio, and television, especially for outside applications. Excellent directivity and compact design.

The venerable MKH 416 is a compact pressure-gradient microphone with short interference tube, highly immune to humidity due to its RF condenser design. Featuring high directivity, low self noise, high consonant articulation and feedback rejection, the MKH 416 can handle difficult exterior filming and reporting conditions without any difficulty. Supercardioid/lobe pattern, matte black finish, supplied with the MZW415 windscreen

Features⁰⁴

Pressure gradient receiver with short interference tube
Hypercardioid at low and medium frequency
Above 2kHz approaches lobar pattern
Color: Black

Top Specs

ColorBlack
DimensionsØ 19 x 250 mm
Weight (g)500
Max. sound pressure level130 dB SPL
Polar patternSupercardioid, Lobar
Transducer principleRF condenser microphone

Tech Specs

Product

Transducer principle
RF condenser microphone
Color
Black
Polar pattern
Supercardioid, Lobar

Frequency Specifications

Audio frequency response
40 - 20,000 Hz

Acoustic Properties

Equivalent noise level (db)
A-weighted 13 dB(A) CCIR-weighted 24 dB
Pick-up pattern
super-cardioid/lobar
Max. sound pressure level
130 dB SPL

Connectivity

Connection
Wired
Connectors
3-pin XLR

Ambient Conditions

Operating temperature (C)
-10 °C to 70 °C (14 °F to 158 °F)

Battery & Power

Battery included
N
Phantom power
48 V ±4 V phantom powering
Charging current (mA)
2 mA

Electrical Properties

Nominal impedance
25 Ω
Min. terminating impedance
800 Ω

Dimensions

Dimensions
Ø 19 x 250 mm
Height (mm)
350
Length (mm)
135
Weight (g)
500
Width (mm)
66
Product height
350
Product length
135
Product weight (g)
175
Product width
66

Downloads¹⁷

Instruction Manuals

Instruction manual - MKH 416
.PDF
·
382.84 KB
Download
Instruction Manual - MKH 416
.PDF
·
382.61 KB
Download
Instrucciones de manejo - MKH 416
.PDF
·
382.85 KB
Download
Notice d'emploi - MKH 416
.PDF
·
385.8 KB
Download
Istruzioni per l'uso - MKH 416
.PDF
·
376.12 KB
Download

Instruction Manual and Frequently Asked Questions

Betjeningsvejledning - MKH 416
.PDF
·
204.86 KB
Download
Käyttöohje - MKH 416
.PDF
·
205.45 KB
Download
Οδηγίες λειτουργίας - MKH 416
.PDF
·
252.98 KB
Download
Gebruiksaanwijzing - MKH 416
.PDF
·
206.1 KB
Download
Instrukcja obsługi - MKH 416
.PDF
·
206.86 KB
Download
Manual de instruções - MKH 416
.PDF
·
205.72 KB
Download
Bruksanvisning - MKH 416
.PDF
·
204.89 KB
Download
Kullanım kılavuzu - MKH 416
.PDF
·
206.39 KB
Download

Spec Sheets

Produktdatenblatt MKH 416
.PDF
·
191.52 KB
Download
Product specification MKH 416
.PDF
·
191.6 KB
Download

EU Declaration of Conformity

EU Declaration of conformity MKH series
.PDF
·
227.71 KB
Download

White Papers

The MKH Story
.PDF
·
1.18 MB
Download

What's in the box⁰³

1 MKH 416 P 48 U 3
1 MZW 415 windshield
1 MZQ 100 microphone clamp

Accessories and spare parts⁰⁶
