SK 2000XP-AW (516-558 MHZ)

Article No. 504048

Features15

  • Sturdy all-metal housing
  • Up to 75 MHz switching bandwidth
  • 20 fixed frequency banks with up to 64 compatible presets
  • 6 banks each with up to 64 tunable channels
  • Frequency setting in 25 kHz steps
  • Pilot tone squelch for interference-free operation
  • External charging contacts for recharging battery BA 2015 in the transmitter
  • Backlit display on transmitter (keystroke activation)
  • Auto-lock feature to prevent buttons from being pressed accidently
  • Audio and RF MUTE feature for muting the transmitter
  • Wide range of accessories for virtually any use
  • Enhanced audio frequency response in the bass range for optimum transmission from bass guitars
  • Input sensitivity above 60 dB can be set in 3 dB steps
  • Transmitters can be configured from the receiver menu
  • Can be synchronized with the receiver using infrared interface

Top Specs

  • Dimensions82 x 64 x 24 mm
  • Weight (g)160 g
  • Input impedance40 kΩ
  • Signal-to-noise ratio> 120 dB(A) (@ 1 mV, peak deviation)

Tech Specs

Product
  • Certifications
    CE , FCC, IC
  • Total harmonic distortion (THD)
    < 0,9 %
Acoustic Properties
  • Signal-to-noise ratio
    > 120 dB(A) (@ 1 mV, peak deviation)
Connectivity
  • Connection
    Wireless
Battery & Power
  • Battery capacity (Ah)
    2.3
  • Battery count
    2
  • Battery included
    Y
  • Battery voltage (V)
    1.5
  • Battery operating time (h)
    typ. 8 h
Electrical Properties
  • Input impedance
    40 kΩ
Dimensions
  • Dimensions
    82 x 64 x 24 mm
  • Height (mm)
    350
  • Length (mm)
    135
  • Weight (g)
    160 g
  • Width (mm)
    66
  • Product height
    350
  • Product length
    135
  • Product weight (g)
    160
  • Product width
    66

Downloads11

chevron-up
  • Safety instructions - 2000 Series | 2000 IEM Series
    .PDF
    ·
    1.06 MB
    Download
  • Outline dimensions SK 2000 (DWG)
    .DWG
    ·
    2.14 MB
    Download
  • Outline dimensions SK 2000 (DXF)
    .DXF
    ·
    7.54 MB
    Download
  • Quick guide 2000 Series
    .PDF
    ·
    1.44 MB
    Download
  • Quick guide EK, SKP, SK, SKM 2000
    .PDF
    ·
    975.76 KB
    Download
  • Manufacturer declarations and specifications - 2000 series
    .PDF
    ·
    4.88 MB
    Download
  • Digital brochure 2000 Series
    .PDF
    ·
    2.34 MB
    Download
  • EU Declaration of Conformity 2000 series
    .PDF
    ·
    1.29 MB
    Download
  • Series 2000 / Series 2000 IEM - Firmware Version 1.8.1
    .ZIP
    ·
    807.09 KB

What's in the box05

  • 1 SK 2000 bodypack transmitter
  • 2 AA 1.5 V batteries
  • 1 instruction manual
  • 1 supplementary frequency sheet
  • 1 supplementary RF power sheet
