MKH 8060

Article No. 506292

Compact shotgun microphone. Provides great sound to feature films, documentaries, outdoor shoots or studio productions. Absolute natural sound and outstanding off-axis linearity. Ideal for camera mounting.

Whether it's a feature film, a documentary, an outdoor shoot or a studio production, the MKH 8060 will provide high quality sound to match your great pictures. Handily compact it shows its strengths as a professional shotgun microphone: The MKH 8060 delivers an absolute natural sound and outstanding off-axis linearity, attenuating sound coming from the side without coloration.

Features¹²

Super-cardioid/lobar pick-up pattern
Very natural sound
Undistorted off-axis sound
Exceptionally low inherent self-noise
Extremely low distortion
Transformerless and fully floating balanced output
High output signal
Rugged metal housing
Non-reflective Nextel® coating
Extremely weather-proof due to RF circuit
Ideal for camera mounting due to compact design
Timbrally identical with the other 8000-series microphones for optimum aural compatibility

Top Specs

Dimensionsdiameter 19 mm, length 175 mm (145 mm excluding XLR module)
Weight (g)501
Audio outputXLR-3M balanced, transformerless, floating
Max. sound pressure level129 dB SPL
Polar patternSupercardioid, Lobar
Sensitivity-24 dBV/Pa (63 mV/Pa)
Transducer principleRF condenser microphone

Tech Specs

Product

Transducer principle
RF condenser microphone
Polar pattern
Supercardioid, Lobar

Frequency Specifications

Frequency response
50 - 25000 Hz
Audio frequency response
50 - 25,000 Hz

Acoustic Properties

Equivalent noise level (db)
A-weighted 11 dB(A) CCIR-weighted 23 dB
Pick-up pattern
super-cardioid/lobar
Max. sound pressure level
129 dB SPL

Inputs/Outputs

Audio output
XLR-3M balanced, transformerless, floating

Ambient Conditions

Operating temperature (C)
-10 °C to 60 °C (14 °F to 140 °F)

Battery & Power

Charging current (mA)
3.3 mA
Phantom powering
48 V +/- 4 V

Electrical Properties

Sensitivity
-24 dBV/Pa (63 mV/Pa)
Nominal impedance
25 Ω
Min. terminating impedance
2 kΩ

Dimensions

Dimensions
diameter 19 mm, length 175 mm (145 mm excluding XLR module)
Height (mm)
82
Length (mm)
245
Weight (g)
501
Width (mm)
170
Product height
82
Product weight (g)
approx. 80 g (0.18 lbs)
Product width
approx. 19 mm (0.75")

Downloads⁰⁸

Technical Drawings

Outline dimensions MKH 8060 (DWG)
.DWG
·
897.18 KB
Download
Outline dimensions MKH 8060 (DXF)
.DXF
·
2.86 MB
Download

Others

MKH 8000 Series Microphone and accessories overview
.PDF
·
1.84 MB
Download
Produktdatenblatt - MKH 8060
.PDF
·
128.14 KB
Download
Product specification - MKH 8060
.PDF
·
127.98 KB
Download
Brochure MKH 8000 Series
.PDF
·
2.02 MB
Download
EU Declaration of conformity MKH 8020, 8040, 8050, 8060, 8070 und 8090
.PDF
·
491.2 KB
Download
The MKH Story
.PDF
·
1.18 MB
Download
