Pick an online PartnerMKH 8040
Article No. 506289
MKH_8040_Product_Shot_Cutout_Front_RGB_red2
MKH 8040
  • MKH_8040_Product_Shot_Cutout_Front_RGB_red2
  • MZW_8000
  • MKH_8000_Case_Product_Shot_Cutout_Isotopview_Closed_RGB_02_red2
  • MKH_8000_Case_Product_Shot_Cutout_Topview_Open_Empty_02_RGB_red2
  • MZQ_8000_Product_shot_cutout_50103
Article No. 506289

MKH 8040

Overview

Versatile cardioid microphone. Especially suited to applications in rooms with poor acoustics or when disturbing sounds impinge mainly from the rear. Balanced frequency response. Extremely low distortion.

The cardioid MKH 8040 is suitable for almost any application. It considerably reduces pick-up of a reverberant room. This is very helpful in rooms with poor acoustics or when disturbing sounds impinge mainly from the rear.

Features09

  • Cardioid pick-up pattern
  • Modular design
  • Wide frequency response 30 to 50.000 Hz
  • Symmetrical transducer with 2 backplates providing extremely low distortion
  • Extremely low inherent self-noise
  • Accurate directional pattern
  • Non reflective Nextel coating
  • Ideal as a spot microphone and for surround recordings
  • Also available in stereo pairs

Top Specs

  • DimensionsØ 19 mm, L 41 mm (74 mm with XLR module)
  • Weight (g)25 g (55 g with XLR module)
  • Audio outputXLR-3M balanced, transformerless, floating
  • Polar patternCardioid
  • Transducer principleRF condenser microphone
Tech Specs
Product
  • Polar pattern
    Cardioid
  • Transducer principle
    RF condenser microphone
Frequency Specifications
  • Frequency response
    30 - 50000 Hz
Acoustic Properties
  • Equivalent noise level (db)
    13 dB
Inputs/Outputs
  • Audio output
    XLR-3M balanced, transformerless, floating
Battery & Power
  • Phantom powering
    48 V +/- 4 V
Electrical Properties
  • Nominal impedance
    25 Ω
  • Min. terminating impedance
    1000 Ω
Dimensions
  • Dimensions
    Ø 19 mm, L 41 mm (74 mm with XLR module)
  • Height (mm)
    82
  • Length (mm)
    245
  • Master carton height (mm)
    388
  • Master carton length (mm)
    354
  • Master carton weight (g)
    517.558
  • Master carton width (mm)
    354
  • Weight (g)
    25 g (55 g with XLR module)
  • Width (mm)
    170
  • Package Depth (mm)
    68
  • Package Height (mm)
    351
  • Package Weight (g)
    858
  • Package Width (mm)
    137
Downloads07
Others
  • Bedienungsanleitung MKH 8040
    .PDF
    ·
    606.32 KB
    Download
  • Bedienungsanleitung MKH 8040 Stereo
    .PDF
    ·
    731.82 KB
    Download
  • Safety instructions MKH 8020, 8040, 8050, 8090
    .PDF
    ·
    671.29 KB
    Download
  • Brochure MKH 8000 Series
    .PDF
    ·
    2.02 MB
    Download
  • EU Declaration of conformity MKH 8020, 8040, 8050, 8060, 8070 und 8090
    .PDF
    ·
    491.2 KB
    Download
  • Microphone and accessories overview MKH 8000 Series
    .PDF
    ·
    191.91 KB
    Download
  • The MKH Story
    .PDF
    ·
    1.18 MB
    Download
What's in the box06
  • Microphone head MKHC 8040
  • XLR module MZX 8000
  • Microphone clip MZQ 8000
  • Windshield MZW 8000
  • User manual
  • Transport case
Accessories and spare parts01
