L 6000

Article No. 507300

Features06

  • 19 inch charging station in 1 RU
  • Flexible configurations with loading modules for handheld transmitters or bodypack battery packs (Digital 6000 and Digital 9000)
  • Quick overview of charging status with three-color LEDs
  • Intelligent charging control with four fans for optimum cooling
  • Storage mode keeps battery packs in optimum charge condition for longer storage periods
  • Integrates into the Wireless Systems Manager

Top Specs

  • Dimensions44 x 483 x 373 mm
  • Weight (g)5.1 kg
  • Charging time (h)BA 60: 80 %: approx. 1:15 h, 100%: approx. 2:30h
  • Power consumption (Amp)Max. 85 W

Tech Specs

Product
  • Display
    Multi-colored
Ambient Conditions
  • Operating relative humidity (≤ %)
    Max. 90 % at 40 °C
Battery & Power
  • Charging time (h)
    BA 60: 80 %: approx. 1:15 h, 100%: approx. 2:30h
  • Power consumption (Amp)
    Max. 85 W
  • Charging current (mA)
    2 A
  • Charging voltage (V)
    4.2 V
Technology
  • Network protocol
    IEEE 802.3-2002 (10/100 Mbit/s), shielded RJ-45 connection
Dimensions
  • Dimensions
    44 x 483 x 373 mm
  • Height (mm)
    175
  • Length (mm)
    550
  • Weight (g)
    5.1 kg
  • Width (mm)
    435
  • Product height
    175
  • Product weight (g)
    5.1 kg
  • Product width
    435

Downloads24

  • Instruction manual - Digital 6000 (v4.0) (PDF)
    .PDF
    ·
    3.2 MB
    Download
  • Safety instructions EM 6000 | L6000
    .PDF
    ·
    837.86 KB
    Download
  • Compliance Sheet EM 6000 (incl. EM 6000 DANTE) | L 6000
    .PDF
    ·
    559.94 KB
    Download
  • Safety instructions LM 6060 | LM 6061 | LM 6062
    .PDF
    ·
    490.26 KB
    Download
  • L 6000 Release Notes v3.0.2
    .PDF
    ·
    105.52 KB
    Download
  • L 6000 Firmware Update V3.0.2
    .ZIP
    ·
    561.11 KB
    Download
  • L6000 Firmware version 3.0.1
    .ZIP
    ·
    561.24 KB
    Download
  • Digital6000_Frequencies_EN
    .PDF
    ·
    120.88 KB
    Download
  • 3D model LM 6060
    .STP
    ·
    6 MB
    Download
  • 3D model LM 6061
    .STP
    ·
    5.78 MB
    Download
  • 3D model L 6000
    .STP
    ·
    22.82 MB
    Download
  • 3D model LM 6062
    .STP
    ·
    6.1 MB
    Download
  • Outline dimensions L 6000 (DWG)
    .DWG
    ·
    2.42 MB
    Download
  • Outline dimensions L 6000 (PDF)
    .PDF
    ·
    283.02 KB
    Download
  • 3rd party control of Sennheiser products using media control protocols
    .PDF
    ·
    211.08 KB
    Download
    • L 6000 | LM 6060 | LM 6061 | LM 6062 | LM 6070 - Quick Guide
      .PDF
      ·
      3.74 MB
      Download
    • Product specification - L 6000
      .PDF
      ·
      306.8 KB
      Download
    • Sennheiser Sound Control Protocol Digital 6000 (EM 6000 | L 6000)
      .PDF
      ·
      547.8 KB
      Download
    • Architect's specification L 6000
      .DOCX
      ·
      13.86 KB
      Download

    What's in the box07

    • 1 L 6000
    • 1 Mains Cable (EU, UK or US plug)
    • 4 Dummy Cover incl. Screws
    • Quick Guide
    • Safety Guide
    • 2 Sticker
    • 4 Rubber Feet
